Package: scimesh 0.4.0

scimesh: Headless Publication-Quality 3D Mesh Rendering Engine

A fast, GPU-free 3D software renderer written in modern C++17 with native R bindings. Renders triangle meshes to publication-quality images entirely on the CPU, requiring no display server or graphics hardware. Features multi-light Blinn-Phong shading, screen-space ambient occlusion, anti-aliasing, depth fog, transparency, wireframe rendering, texture mapping, screen-space lines and text labels, and procedural geometry generation. Supports standard mesh file formats with PNG and PPM output. Works on high-performance computing clusters, headless servers, containers, and continuous integration pipelines, making it suitable for scientific visualization across neuro-imaging, molecular structures, and general 3D graphics.

Authors:Tim Schäfer [aut, cre], Martin Hořeňovský [ctb], Christophe Riccio [ctb], Dimitri Diakopoulos [ctb], Tim Schäfer [ctb], Sebastian Reiter [ctb], Sean Barrett [ctb], Rasmus Andersson [ctb]

scimesh_0.4.0.tar.gz
scimesh_0.4.0.zip(r-4.7-x86_64)scimesh_0.4.0.zip(r-4.7-arm64)scimesh_0.4.0.zip(r-4.6-x86_64)scimesh_0.4.0.zip(r-4.6-arm64)scimesh_0.4.0.zip(r-4.5-x86_64)
scimesh_0.4.0.tgz(r-4.6-x86_64)scimesh_0.4.0.tgz(r-4.6-arm64)scimesh_0.4.0.tgz(r-4.5-x86_64)scimesh_0.4.0.tgz(r-4.5-arm64)
scimesh_0.4.0.tar.gz(r-4.7-arm64)scimesh_0.4.0.tar.gz(r-4.7-x86_64)scimesh_0.4.0.tar.gz(r-4.6-arm64)scimesh_0.4.0.tar.gz(r-4.6-x86_64)
scimesh_0.4.0.tgz(r-4.6-emscripten)
manual.pdf |manual.html✨
DESCRIPTION
card.svg |card.png
scimesh/json (API)

# Install 'scimesh' in R:

install.packages('scimesh', repos = c('https://dfsp-spirit.r-universe.dev', 'https://cloud.r-project.org'))

Bug tracker:https://github.com/dfsp-spirit/scimesh/issues

Uses libs:

c++– GNU Standard C++ Library v3

On CRAN:

computergraphics cplusplus mesh renderer software-renderer triangle-mesh visualization cpp

4.78 score 1 stars 15 scripts 300 downloads 75 exports 1 dependencies

Last updated from:bec57aa998 (on v0.4.0). Checks:2 ERROR, 13 OK. Indexed: yes.

Target	Result	Time
linux-devel-arm64	ERROR	139
linux-devel-x86_64	OK	157
source / vignettes	OK	263
linux-release-arm64	ERROR	138
linux-release-x86_64	OK	161
macos-release-arm64	OK	146
macos-release-x86_64	OK	228
macos-oldrel-arm64	OK	123
macos-oldrel-x86_64	OK	251
windows-devel-arm64	OK	290
windows-devel-x86_64	OK	172
windows-release-arm64	OK	259
windows-release-x86_64	OK	155
windows-oldrel-x86_64	OK	144
wasm-release	OK	116

Exports:apply_colormap bezier_path camera camera_auto camera_fit_scene camera_orbit clip_plane colorbar_horizontal colorbar_vertical compose_layout compute_vertex_normals default_font diverging_colormap flip_uvs font_info generate_arrow generate_axes generate_bbox generate_cone generate_cuboid generate_cylinder generate_multi_cylinders generate_multi_spheres generate_plane generate_pyramid generate_sphere generate_tetrahedron generate_torus generate_tube generate_tubes image_apply_contrast image_crop image_crop_to_content image_grow image_merge image_rotate_90 image_scale image_to_array line_layer mesh_bbox mesh_from_rgl mesh_to_rgl path_curvature path_length read_obj read_ply read_stl render_lines render_mesh render_options render_points render_scene render_segments render_spheres render_text render_triangles resample_path rotate_mesh scale_mesh scene scene_set_line_affects_bounds set_mesh_alpha spline_path stack_horizontal stack_vertical text_extent text_layer transform_mesh translate_mesh viridis_colormap world_to_screen write_gltf write_png write_stl write_tga

Dependencies:Rcpp

Getting Started with scimesh

Rendered fromscimesh.Rmdusingknitr::rmarkdown

Last update: 2026-09-17
Started: 2026-07-11

Help page	Topics
Apply a colormap to numerical data	apply_colormap
Sample a Bezier curve from a control polygon	bezier_path
Create a camera specification	camera
Auto-frame a camera to fit a mesh or vertex set	camera_auto
Fit a camera to a whole scene	camera_fit_scene
Orbit a camera around an axis	camera_orbit
Create a clip plane specification	clip_plane
Generate a horizontal colorbar image	colorbar_horizontal
Generate a vertical colorbar image	colorbar_vertical
Compose multiple images into a single figure	compose_layout
Compute per-vertex normals for a mesh	compute_vertex_normals
Path of the font used for text labels	default_font
Custom diverging colormap for neuroimaging	diverging_colormap
Flip the texture coordinates of a mesh vertically	flip_uvs
Information about the font used for text labels	font_info
Generate an arrow mesh	generate_arrow
Generate XYZ axis arrows as cylinder meshes	generate_axes
Generate a wireframe bounding box mesh	generate_bbox
Generate a cone mesh	generate_cone
Generate a cuboid mesh	generate_cuboid
Generate a cylinder mesh	generate_cylinder
Generate multiple cylinders as a single mesh	generate_multi_cylinders
Generate multiple spheres as a single mesh	generate_multi_spheres
Generate a planar quad mesh	generate_plane
Generate a square pyramid mesh	generate_pyramid
Generate a sphere mesh	generate_sphere
Generate a tetrahedron mesh	generate_tetrahedron
Generate a torus mesh	generate_torus
Generate a tube (generalized cylinder) along a path	generate_tube
Generate multiple tubes as a single mesh	generate_tubes
Apply contrast adjustment to an image	image_apply_contrast
Crop an image to a rectangular region	image_crop
Crop an image to its content bounding box	image_crop_to_content
Grow an image by adding padding	image_grow
Merge two images side by side or stacked	image_merge
Rotate an image by 90 degrees	image_rotate_90
Scale an image (nearest-neighbour)	image_scale
Convert a rendered image to an RGBA array	image_to_array
Create a line layer (screen-space lines, no geometry)	line_layer
Compute the axis-aligned bounding box of a mesh	mesh_bbox
Convert an rgl tmesh3d to scimesh mesh format	mesh_from_rgl
Convert a scimesh mesh to rgl tmesh3d format	mesh_to_rgl
Curvature along a path	path_curvature
Length of a path	path_length
Read a Wavefront OBJ file	read_obj
Read a Stanford PLY file	read_ply
Read an STL file	read_stl
Render line segments as thin cylinders	render_lines
Render a 3D mesh to an image	render_mesh
Create render options	render_options
Render screen-space point primitives	render_points
Render multiple meshes to an image	render_scene
Render line segments directly to an image	render_segments
Render multiple spheres from point data	render_spheres
Render text labels to an image	render_text
Render raw triangles without index buffer	render_triangles
Resample a path at a fixed arc length step	resample_path
Rotate a mesh around an axis	rotate_mesh
Scale a mesh uniformly or per-axis	scale_mesh
Create a scene descriptor	scene
Change whether line layers of a scene contribute to its bounds	scene_set_line_affects_bounds
Set the transparency of a whole mesh	set_mesh_alpha
Smooth curve through ordered 3D points	spline_path
Stack images horizontally	stack_horizontal
Stack images vertically	stack_vertical
Measure text	text_extent
Create a text label layer (2D annotations for a scene)	text_layer
Apply a 4x4 transformation matrix to a mesh	transform_mesh
Translate a mesh	translate_mesh
Viridis colormap	viridis_colormap
Project world coordinates to image pixels	world_to_screen
Write a scene or mesh list to a glTF file	write_gltf
Write a rendered image to a PNG file	write_png
Write a mesh to an STL file	write_stl
Write a rendered image to a TGA file	write_tga
